Siglent SDS804X HD
A bench oscilloscope with its own 7-inch screen. Four analog channels and four passive probes are in the box. The logic probe is a separate purchase.
$521
Buy $521One SDS804X HD. Stripe checkout collects your card and ship-to address. US shipping included. Ships to the US and Canada.
What it does
- Shows analog waveforms on its own screen
- Measures four channels at 12-bit resolution
- Triggers and decodes I2C, SPI, UART, CAN, and LIN
- Ships with one passive probe on each channel
The unit you receive
This listing is the Siglent SDS804X HD. It is the 70 MHz, 4-channel model. The 2-channel SDS802X HD, the 100 MHz models, and the 200 MHz models are different products. The Saleae Logic 8 already sold here is a USB logic analyzer. This oscilloscope is a separate instrument with its own display.
Sample rate and memory are shared. Datasheet EN01D rates this model at 2 GSa/s and 50 Mpts on one channel, 1 GSa/s and 25 Mpts on two channels, and 500 MSa/s and 10 Mpts when all four channels are on. Siglent rates the capture rate at 80,000 waveforms per second in normal mode and 500,000 in sequence mode. The screen is a 7-inch capacitive touch display, 1024×600. The included serial trigger and decode covers I2C, SPI, UART, CAN, and LIN.
The box is the oscilloscope, one USB cable, a quick start, four PB470 passive probes, a calibration certificate, and a power cord. Each PB470 is 1x/10x. Siglent rates it at 6 MHz in the 1x position and 70 MHz in the 10x position. These probes are not a mains probe. The 16 digital channels need the SLA1016 logic probe and the SDS800XHD-16LA license. The SAG1021I waveform generator, the SDS800XHD-PA power-analysis software, and the DF2001A deskew fixture are also sold separately.
Power is 100–240 V, 50/60 Hz. Siglent rates consumption at 80 W maximum, 40 W typical, and 4 W in standby. Size is 312 × 151 × 132.6 mm, about 12.3 × 5.9 × 5.2 inches, including the knobs and feet. Net weight is 2.6 kg, about 5.7 lb. Siglent Technologies NA publishes a 3-year warranty on the instrument and 1 year on accessories when the unit is bought through Siglent America or an approved North American distributor. That period starts on the authorized invoice. This shop does not add its own warranty. A dealer’s return window is not this shop’s policy.
Specs
| Model | SDS804X HD. 70 MHz, 4 analog channels, 12-bit. |
|---|---|
| Sample rate | 2 GSa/s one channel, 1 GSa/s two channels, 500 MSa/s four channels. |
| Memory | 50 Mpts, 25 Mpts, and 10 Mpts per channel, in that same order. |
| Capture rate | 80,000 wfm/s normal. 500,000 wfm/s sequence. Siglent’s rating. |
| Screen | 7-inch capacitive touch, 1024×600 |
| Decode | I2C, SPI, UART, CAN, and LIN included |
| Probes | Four PB470 passive probes. 6 MHz at 1x, 70 MHz at 10x. Not a mains probe. |
| Sold separately | SLA1016 logic probe and SDS800XHD-16LA license. SAG1021I generator. SDS800XHD-PA. DF2001A. |
| Power | 100–240 V, 50/60 Hz. 80 W max. |
| Size | 312 × 151 × 132.6 mm including knobs and feet. 2.6 kg. |
| In the box | Oscilloscope, USB cable, quick start, four probes, calibration certificate, power cord |
| Price | USD, US shipping included |
Bandwidth, sample rate, memory, capture rate, and probe ratings are Siglent’s figures for the SDS804X HD in datasheet EN01D. The unit you receive is that model. Studio photo shows the listing.
